Clear Floor Maha Lifts

ATS ELGI in collaboration with MAHA Germany offers you, MAHA electro- mechanical two post lift. With high safety features and additional benefits it ensures that you save time, money and power.

Parameters	Model : CFL S3000	Model: MAHA 3.5 T
Load Capacity (CE Rated)	3.0 Ton	3.5 Ton
Lifting height (Max.)	1990 mm	1990 mm
Lifting Height (Min)	85 mm	85 mm
Lifting/ Lowering time	40 Sec	40 Sec

Applications

• Muffler repair.
• Rust proofing operations.
• Transmission repair.
• Any other repair calling for a wheel- free condition.

Benefits

• Long life by HWR System.
• High stability by optimized carriage and column profile.
• High safety level by positive engagement of toothed arm resistant.
• Danger zone monitoring with acoustic signal.
• Stress- free support of lifting screw by articulated friction bearing.
• Asymmetrical lifting carriage and support arms for ample door clearance.
• Short support arms with 180˚ swivel range.

Key Features

• Wear- resistant, maintenance- free.
• Proximity switches for non-contact height measurement.
• Permanent self monitoring of all safety functions:
  • Synchronizing
  • Phase failure
  • Belt failure
  • Load nut failure
  • Motor overload
  • Electronic shutdowns at limit stop and if obstruction detected
